In perfecte staat.

Specificaties

Continuous rated power output (DIN) 1kHz
at 8ohm 70W + 70W
at 4ohm 90W + 90W
(IEC/NF) From 63 Hz to 12,500 Hz. 0.7% T.H.D.
at 8ohm 70W + 70W
at 4ohm 90W + 90W

Dynamic power
90W (8ohm)
120W (4ohm)

Damping factor
200 (50 Hz)

Total harmonic distortion
0.06% (20Hz - 20,000Hz, 60W, 8ohm)
0.02% (1 kHz, 60W, 8ohm)

Intermodulation distortion
0.02% (60 W, 8ohm) (70Hz :7kHz = 4:1)

Frequency response (IHF '78)
TUNER/AUX/TAPE1, 2/CD
5Hz - 100kHz, +0dB, -3dB

PHONO 'RIAA' response
20Hz - 20kHz.
+0.3dB, -0.3dB

Maximum input level
PHONO (MM) 120mV, 0.05% T.H.D. at 1kHz
PHONO (MC) 10mV, 0.05% T.H.D. at 1kHz

Signal to noise ratio
PHONO (MM)
87dB (IHF '66)
79dB (IHF '78)
PHONO (MC)
67dB (IHF '66)
74dB (IHF 78)
TUNER/AUX/TAPE1,2/CD
104dB (IHF '66)
80dB (IHF 78)
PHONO (MM)
58dB (DIN, 50mW output)
TUNER/AUX/TAPE1,2/CD
59dB (DIN, 50mW output)

Input sensitivity/impedance
PHONO (MM) 2.5 mV/47kohm
PHONO (MC) 0.2 mV/100ohm
TUNER/AUX/TAPE1,2/CD 200 mV/47kohm

Tone control
BASS ±10 dB (at 100 Hz)
TREBLE ±10 dB (at 10 kHz)
Loudness control (VOLUME at-30 dB level)
+6 dB (100 Hz)
+3 dB (10 kHz)

Output level/impedance
TAPE REC 200 mV/1kohm

General
Power consumption 220 W (IEC)
Switched AC outlets 3 (Total 200W max.)
Dimensions W:440mm - H:137mm - D:345mm
Weight (net) 8.5kg
