Technical Specifications
General:
Type: 2-channel professional audio interface with DSP
Purpose: Recording, mixing, mastering
Analog Inputs:
2 balanced combo inputs (XLR / TRS)
Mic/Line inputs with high-quality preamps
Phantom power available on each channel (for condenser mics)
Analog Outputs:
2 balanced line outputs (TRS)
2 monitor outputs (TRS)
Stereo analog send/return
Digital I/O:
AES/EBU digital input/output (1 pair)
S/PDIF optical and coaxial input/output
Converters:
A/D and D/A converters: 24-bit resolution
Dynamic range: 110 dB (A/D), 120 dB (D/A)
Sample rates: 44.1 kHz up to 192 kHz
DSP and Processing:
Built-in DSP with Sonic EQ and 90+ plug-ins
Real-time effects on recording and monitoring
DSP-based mixing and mastering tools
Connectivity:
Dual FireWire 400 (IEEE 1394a) host connectors
Bus powered or mains powered options
Fully compatible with Mac OS X Core Audio (native support)
Physical Characteristics:
Compact rackmount form factor
Rugged metal chassis
Weight: approximately 3-4 kg
