Kenmerken
Conditie
Gebruikt
Beschrijving
Receiver
Common Frequency Options: 8kHz, 33kHz, 82 kHz,118kHz & 200kHz
Passive Frequency Options: 50Hz, 60Hz, CP, CATV
Antenna Mode: Peak & Left/Right
Display Indicators: LCD bar graph, low battery, signal strength, and mode indicators
Audio Indication: Variable pitch response
Power Source: 6 “AA” cell batteries
Battery Life: Continuous: 30 hours
Intermittent: 60 hours
Signal Strength: LCD bar graph Absolute signal strength 0-99
Gain Control: Manual gain adjustment
Dynamic Range: 126 dB
Depth Estimation: Push button digital depth & Triangulation method
Transmitter
Operating Frequency Options: 8kHz, 33kHz, 82 kHz, 118kHz & 200kHz
Indicators: AC load assistance measurement, low battery indicator with modulated low battery warning
Load Matching: Automatic from 5 ohms to 25,000 ohms
Output Power: 3 power settings, Low Range 0.2 W 3 W, Med Range 0.2 W 3 W High Range 0.2 W 1 W
Power Source: 8 “C” cell batteries
Battery Life: (dependant on load, frequency, power setting) Continuous, 8-15 hours Intermittent, 40-60 hours
Common Frequency Options: 8kHz, 33kHz, 82 kHz,118kHz & 200kHz
Passive Frequency Options: 50Hz, 60Hz, CP, CATV
Antenna Mode: Peak & Left/Right
Display Indicators: LCD bar graph, low battery, signal strength, and mode indicators
Audio Indication: Variable pitch response
Power Source: 6 “AA” cell batteries
Battery Life: Continuous: 30 hours
Intermittent: 60 hours
Signal Strength: LCD bar graph Absolute signal strength 0-99
Gain Control: Manual gain adjustment
Dynamic Range: 126 dB
Depth Estimation: Push button digital depth & Triangulation method
Transmitter
Operating Frequency Options: 8kHz, 33kHz, 82 kHz, 118kHz & 200kHz
Indicators: AC load assistance measurement, low battery indicator with modulated low battery warning
Load Matching: Automatic from 5 ohms to 25,000 ohms
Output Power: 3 power settings, Low Range 0.2 W 3 W, Med Range 0.2 W 3 W High Range 0.2 W 1 W
Power Source: 8 “C” cell batteries
Battery Life: (dependant on load, frequency, power setting) Continuous, 8-15 hours Intermittent, 40-60 hours
...
...
...
...
...
...
...
...
...
...
...
...
Berlare
49x bekeken
0x bewaard
Sinds 26 mei '26
Zoekertjesnummer: m2403756379
