4K HDMI switcher/scaler

Kramer VP-440X Switcher/Scaler

Switcher/Scaler

• 18G 4K 4:4:4 presentation switcher / scaler with parallel HDBaseT and HDMI outputs
• Supports up to 4K@60 4:4:4 on the HDMI output
• Supports up to 4K@60 4:2:0 on the HDBaseT output
• HDBaseT Maximum range 70 m at 1080p, 40 m at 4K@60Hz 4:2:0
• Analogue audio and microphone signal embedding
• CEC support for switching displays on and off
• Scaling up and down from and to all common resolutions

Technical data:

• 4 HDMI inputs
• 1 VGA input: 5-pin HD connector
• 5 Unbalanced stereo analogue audio inputs: 3.5 mm mini jack socket
• 1 Microphone input: 6.3 mm jack socket
• 1 HDMI output
• 1 HDBaseT output: RJ-45 socket
• 1 Unbalanced analogue audio output: 3.5 mm mini-jack socket
• 1 Ethernet: RJ-45 socket
• 1 Data RS-232: 3-pin terminal block for serial link extension
• 1 CTRL RS-232: 3-pin terminal block for device control
• 6 NO contacts: 7–pin terminal block connector
• 1 USB: USB-A socket for firmware upgrades
• Cooling: Convection ventilation
• Material: Aluminium
• Power supply: 5V DC, 4A
• Power consumption: 19 W
• Dimensions: 21.46 x 16.30 x 4.36 cm
• Weight: 1.1 kg
• Includes power supply unit and rubber feet

Video:

• Max. resolution: 4K@60Hz (4:4:4)
• Max. transfer rate: 18 Gbps (6 Gbps per graphics channel)
• Standards: Complies with HDCP1.4 & 2.2 and supports HDR10
• Input resolutions HDMI: 480i/576i, 480p/576p, 720p@60/50Hz, 1080i@60/50Hz, 1080p@60/50Hz, 1080p@24/25/30Hz, 640x480@60/67/72/75/85Hz, 800x600@56/60/72/75Hz, 1024x768@60/70/75Hz, 1280x1024@60/75Hz, 1280X960@60Hz, 1280X720@60Hz, 1920X1080@60Hz, 1600X1200@60Hz, 1280x768@60Hz, 1280x800@60Hz, 1360x768@60Hz, 1366x768@60Hz, 1400x1050@60Hz, 1600X900@60Hz RB, 1680x1050@60Hz, 1920x1200@60Hz RB, 2048x1080@24/25/30/50/60Hz, 4K/2K@24/25/30/50/60Hz, 4K/2K(4: 2:0)@50/60Hz
• Input resolutions VGA: 640x480@60/67/72/75/85Hz, 800x600@56/60/72/75Hz, 1024x768@60/70/75Hz, 1280x1024@60/75Hz, 1280X960@60Hz, 1280X720@60Hz, 1920X1080@60Hz, 1600X1200@60Hz, 1280x768@60Hz, 1280x800@60Hz, 1360x768@60Hz, 1366x768@60Hz, 1400x1050@60Hz, 1600X900@60Hz RB, 1680x1050@60Hz, 1920x1200@60Hz RB
• Output resolutions: 640x480@60Hz, 800x600@60Hz, 1024x768@60Hz, 1280x768@60Hz, 1280x800@60Hz, 1280x1024@60Hz, 1360x768@60Hz, 1400x1050@60Hz, 1440x900@60Hz, 1600x1200@60Hz, 1680x1050@60Hz, 1920x1200@60Hz RB, 1920x1080@60Hz, 1280x720@60Hz, 720x480p@60Hz, 720x576p@50Hz, 1280x720p@50/60Hz, 1920x1080p@24/25/30/50/60Hz
• Output resolutions 4K-HDMI : 4K@24/25/30/50/60Hz (4:4:4)
• Output resolutions 4K-HDBaseT: 4K@24/25/30Hz (4:4:4), 4K@50/60Hz (4:2:0)
• Switching time between inputs : 3 seconds
• Video latency: 1-2 frames
• Extension cable up to 40 m : at 4K@60Hz (4:2:0)
• Extension cable up to 70 m: with full HD (1080p @60Hz 36bpp)
