The Fireface 800 is the world's most powerful FireWire audio interface ever. Up to 56 channels record/playback, up to 192 kHz sample rate, and true FireWire 800 sum up to an unsurpassed high-end, high performance and high speed FireWire audio interface. Since the Fireface first shipped in July 2004, the unit became the reference for FireWire audio - and still is today!

Digital I/Os: Two ADAT optical I/Os allow for a connection and insertion of effects devices, mixing consoles or external converters. Of course, these 16 channels are available simultaneously with the analog channels. Using two additional ADI-8 DS, there are 26 analog inputs and outputs, which remain still 18 at 96 kHz. The coaxial SPDIF I/O works up to 192 kHz, so that there are still 10 analog in- and outputs at the highest sample rate, plus two digital ones.
Input AD: 8 x 1/4" TRS, 4 x XLR Mic, 4 x 1/4" TRS Line, all servo-balanced. 1 x 1/4" TS unbalanced
Output DA: 8 x 1/4" TRS, servo-balanced, DC-coupled signal path. 1 x 1/4" TRS unbalanced
Input Digital: 2 x ADAT optical or SPDIF optical, SPDIF coaxial (AES/EBU compatible)
Output Digital: 2 x ADAT optical or SPDIF optical, SPDIF coaxial (AES/EBU compatible)
MIDI: 1 x MIDI I/O via 5-pin DIN jacks, for 16 channels low jitter hi-speed MIDI
