Key feature
System function:
 SONY high performance sensor, up to 1280x960 resolution
 ±0.1° Preset Accuracy
 CGI(Common Gateway Interface) 、 PSIA(Physical Security Interoperability Alliance), to ensure greater
interoperability between different platforms and compatibility
 3D intelligent positioning function
 Power-off memory function: restore PTZ & Lens status after reboot
 Fiber optical interface optional
 Scheduled PTZ movement
Camera function:
 Auto iris, auto focus, auto white balance, internal synchronization, backlight compensation and auto day & night
switch
 Pravacy Mask programmable
PTZ function:
 360° endless pan range and -5°-90° tilt range
 540°/s Pan Preset Speed and 400°/s Tilt Preset Speed
 0.1°-300°/s Manual Pan Speed and 0.1°-240°/s Manual Tilt Speed
 256 presets programmable, preset image freezing capability
 8 patrols, up to 32 presets per patrol
 4 patterns, with the recording time not less than 10 min per pattern
 Park action: auto callup of PTZ movement, after a defined time of inactivity
 2 alarm inputs and 2 alarm outputs（7 alarm inputs and 2 alarm outputs optional）
Network function:
 H.264/MJPEG video compression and the latest DaVinci processing chip and platform
 Built-in Web server
 SD/SDHC card local storage
 Dual stream
 Multiple network protocols supported: IPv4, HTTP, FTP, SMTP, SNMP, DNS, NTP, RTSP, RTP, TCP, UDP, IGMP,
