Fostex Effect Processor DE-1

SPECIFICATIONS

INPUT/OUTPUT
Connector ∅ 6 mm phone jack / unbalanced
Input level -10 dBV
Impedance 20 kΩ or more
STEREO OUTPUT (L & R)
Connector ∅ 6 mm phone jack / unbalanced
Output level -10 dBV
Impedance 10 kΩ or more
FOOT SWITCH (x 1) ∅ 6 mm phone jack (Optional Model 8051)

OTHERS
Frequency Response + 1, -2 dB at 20 Hz ~ 14.5 kHz
Dynamic Range 86 dB (IHF A)
AD / DA Converter 20-bit
Total Harmonic Distortion 0.1 % at 100 Hz ~ 10 kHz (w / LPF)
Crosstalk 60 dB at 1 kHz
Sampling Frequency 32 kHz

GENERAL
Dimensions 220 (W) × 187 (D) × 43 (H) mm
Weight 1.0 kg (excluding AC adaptor)

Power Requirement
Power supply DC 9 V (center: positive), 600 mA
AC Adaptor AD-9B

STANDARD ENVIRONMENT
Standard Temperature 20 ± 2 ºC
Standard Humidity 65 ± 5 %

ENVIRONMENT CONDITION
Characteristics Guaranteed
Temperature + 5 ºC ~ + 40 ºC
Humidity 30 ~ 70 %
AC voltage deviation ± 5 % or less
Operation Guaranteed
Temperature +- 5 ºC ~ + 45 ºC
Humidity 85 % or less
AC voltage deviation ± 10 % or less
