Dell PowerEdge R510 8 Slots LFF (3.5")

Feature PowerEdge R510 Technical Specification Form Factor 2U rack Processors Quad-core or six-core Intel® Xeon® processors 5500 and 5600 series Processor Sockets 2 Front Side Bus or HyperTransport Intel QuickPath Interconnect (QPI) Cache 4MB, 8MB and 12MB Chipset Intel 5500 Memory1 Up to 128GB (8 DIMM slots): 1GB/2GB/4GB/8GB/16GB DDR3 up to 1333MHz I/O Slots 3 PCIe G2 slots + 1 storage slot: One x8 slot Two x4 slots One storage x4 slot RAID Controller Internal: SAS 6/iR PERC 6/i PERC S100 (software based), Available on 4 HDD only PERC S300 (software based), Available on 4 and 8 HDD only PERC H200 (6GB/s) PERC H700 (6Gb/s) with 512MB battery-backed cache; 512MB, 1GB Non-Volatile battery-backed cache External: PERC H800 (6Gb/s) with 512MB of battery-backed cache; 512MB, 1GB Non-Volatile battery-backed cache PERC 6/E with 256MB or 512MB of battery-backed cache SAS 5/E HBA LSI2032 PCIe SCSI HBA External HBAs (non-RAID): 6Gbps SAS HBA SAS 5/E HBA LSI2032 PCIe SCSI HBA Drive Bays Up to four cabled 3.5” SAS or SATA drives in 4 hard drive chassis Up to eight hot-swap 2.5”/3.5” SAS, SATA or SSD drives in 8 hard drive chassis Up to 12 hot-swap 2.5”/3.5” SAS, SATA or SSD drives in 12 hard drive chassis with 2 additional 2.5” internal cabled hard drives Maximum Internal Storage1 12TB–37.8TB (depending on chassis) Hard Drives Hot-plug hard drive options: 2.5” SAS SSD, SATA SSD, SAS (10K) 3.5” SAS (15K, 10K), nearline SAS (7.2K), SATA (7.2K) Cabled hard drive options: 2.5” SATA SSD, SAS (10K), nearline SAS (7.2K) 3.5” SAS (15K, 10K), nearline SAS (7.2K), SATA (7.2K) Communications Intel 10G Base-T Single Port NIC Broadcom® BMC5710 10 Base-T Copper Single Port NIC Intel PRO/1000 PT Single Port Adapter, Gigabit Ethernet NIC, PCIe x1 Intel Gigabit ET Dual Port Adapter, Gigabit Ethernet NIC, PCIe x4 Intel Ethernet X520 DA2 Dual-Port 10 Gigabit Server Adapter Intel Gigabit ET Quad Port Adapter, Gigabit Ethernet NIC, PCIe x4 Emulex® CNA iSCSI HBA stand up adapter OCE10102-IX-D Emulex CNA iSCSI HBA stand up adapter OCE10102-FX-D Broadcom NetXtreme® 5709 Dual Port Gigabit Ethernet NIC, Copper, TOE/iSCSI PCIe x4 Broadcom NetXtreme II 57711 Dual-Port SFP+/Direct Attach 10Gb Ethernet PCI-Express Network Interface Card with TOE and iSCSI Offload Broadcom NetXtreme 5709 Dual Port Gigabit Ethernet NIC, Copper, w/TOE PCIe x4 Brocade® CNA Dual-port adapter Brocade FC4 and 8 GB HBAs Brocade CNA BR1020 Power Supply 4 hard drive configuration: • Non-redundant 480W power supply 8 hard drive configuration: • One non-redundant 750W hot-plug power supply • One non-redundant 1100W hot-plug power supply • Two redundant 750 hot-plug power supplies • Two redundant 1100W hot-plug power supplies 12 hard drive configuration: • One non-redundant 750W hot-plug power supply • Two redundant 750 hot-plug power supplies Uninteruptible power supplies: • 1000W-5600W • 2700W-5600W High Efficiency Online • Extended Battery Module (EBM) • Network Management Card
