Opton Aramid Z-XOTKtcdD universal fiber optic cable 12 fiber

Opton Aramid Z-XOTKtcdD universal fiber optic cable 12 fibers G.652D


Gekocht voor een project dat niet meer doorgaat, nieuw op rol
2 rollen van 4KM beschikbaar, prijs per rol



Eventueel GPON splitters te verkrijgen en slings.
Factuur mogelijk


Specs:

Opton Aramid Z-XOTKtcdD is an universal optical cable with 12 fibers G.652.D. The fibers are located in one, central tube with 2 mm of diameter. Construction was reinforced with numerous aramid fibers, thanks to that the cable is distinguished by high tensile strength - up to 600 N (strength of installation - 1200 N). Two rods ARP or FRP with 0,5 mm of diameter are another reinforcement.

The external cover was made out of high wuality HDPE, its nominal largeness is of 1,4 mm. Optical fiber is totally non-conducting. Cable can be used in teletechnical canalization or in aerial installations. Maximal arc in aerial installations are of 50 m.

The product is of small diameter (+- 5,3 mm) and weight (+- 22 kg/km), but at the same time it's very resistant and strong.



Suggested slings:


2.1 PA (35 200)
2.3

The most important features:

12 fibers G.652.D;

one, central tube;

universal cable;

assemblage in teletechnical canalization or aerial installation;

more or less 5,3 mm of diameter;

maximal arc: 50 m;

tensile strength: up to 600 N (temporary 1200 N);

aramid reinforcement;

2 rods ARP or FRP.
