CPU Marvell 6281 800MHz
DRAM 256MB DDRII RAM
Flash Memory 16MB
HDD 4 x 3.5" or 2.5” SATA I/II HDD
NOTE: The system is shipped without HDD.
HDD Tray
4 x hot-swappable and lockable tray
LAN Port
2 x Gigabit RJ-45 Ethernet port
LED Indicators
Status, LAN, USB, eSATA, HDD 1, HDD 2, HDD 3, HDD 4
USB
4 x USB 2.0 port (Front: 1; Back: 3)
Supports USB printer, disk, pen drive, USB hub, and USB UPS, etc.
eSATA
2 x eSATA port (Back)
Buttons
Power button, USB one-touch-backup button, reset button
Alarm Buzzer
System warning
Form Factor
Tower
Dimensions
177(H) x 180(W) x 235(D) mm
6.97(H) x 7.09(W) x 9.25(D) inch
Weight
Net weight: 3 Kg (6.61 lbs)
Gross weight: 4.6 Kg (10.14 lbs)
Sound Level (dB)
Without HDD: 33.0dB
Standby: 33.2dB
In operation: 35.1dB
(Background: 25.5dB)
Power Consumption (W)
Sleep mode: 12W
In operation: 20W
(with 4 x 500GB HDD installed)
Temperature
0~40˚C/ 32~104°F
Humidity
0~95% R.H.
Power Supply
Input: 100-240V AC, 50/60Hz, Output: 12V DC, 10A, 120W
Secure Design
K-Lock security slot for theft prevention
Fan
1 x quiet cooling fan (9 cm, 12V DC)
