Yamaha Vintage stereo-set from the 90's

Yamaha Vintage stereo-set from the 90's

Voor diegene die weer heerlijk van vinyl, cassettebandjes, cd's en radio wil gaan genieten.
Met deze complete set kunt u gelijk van start gaan!

Set verkeert in goede perfect werkende staat!
Incl. meubel
Incl. speakers + speakerstands met spikes.
Incl. afsb. voor cd speler

Platenspeler met nieuwe Audio-technica naald en nieuwe aandrijfsnaar.
Ook het cassettedeck is reeds voorzien van nieuwe aandrijfsnaren, speelt loepzuiver en neemt perfect op.

Set bestaande uit de volgende componenten:

Yamaha TT-400 Full-automatic platenspeler
Specs.
Drive system: belt drive
Motor: DC motor
Platter: aluminium diecast
Speeds: 33 and 45rpm
Signal to noise ratio: 70dB
Wow and flutter: 0.045% WRMS
Arm type: static balance, straight arm tube
Effective length: 230mm
Overhang: 16mm
Effective mass: 9.5g
Tracking force: 0 to 3g
Offset angle: 23 degrees
Cartridge weight: 4 to 9g
Dimensions: 430 x 110 x 375mm
Weight: 4.0kg
Year: (1987-93)

Yamaha TX-340 tuner
Specs.
Reception: (FM/MW)
Frequencies:
VHF/FM: 87.5 to 108 MHz
AM/MW: 531 to 1.611 kHz
Frequency response 0±0.5: 30 Hz to 13 kHz
Frequency response 0±1.5: 20 Hz to 15 kHz
Input sensitivity: 100 μV/m
Distortion factor: 0.1%/0.2%
Channel separation: 1 kHz 40 dB
Selectivity: 85 dB
Image frequency attenuation: 75 db
IF attenuation: 75 dB
AM suppression: 55 dB
Output level: 500 mV/2.2 kOhm
RDS: No
Station memory: 16
Year: (1990-91)

Yamaha AX-540 versterker
Specs.
Power output: 85 watts per channel into 8Ω (stereo)
Frequency response: 20Hz to 20kHz
Total harmonic distortion: 0.01%
Damping factor: 80
Input sensitivity: 0.16mV (MC), 2.5mV (MM), 150mV (line)
Signal to noise ratio: 76dB (MC), 92dB (MM), 102dB (line)
Channel separation: 60dB (MM), 60dB (line)
Output: 150mV (line)
Dimensions: 435 x 139 x 330 mm
Weight: 8kg
Year: (1990-91)

Yamaha CDX-590 cd speler
Specs.
Disc format: CD
Digital converter: YAC514
CD Mechanism: KSS-210A
Frequency response: 2Hz to 20kHz
Dynamic range: 98dB
Signal to Noise Ratio: 115dB
Total harmonic distortion: 0.0025%
Line output: 2V
Digital connections: coaxial, optical
Dimensions: 435 x 96 x 272mm
Weight: 3.8kg
Accessories: remote control
Year: (1997)

Yamaha KX-580 cassettedeck
Specs.
Type: 2-head, single compact cassette deck
Track System: 4-track, 2-channel stereo
Tape Speed: 4.76 cm/s
Heads: 1 x record/playback, 1 x erase
Motor: 1 x reel, 1 x capstan
Tape Type: type I, CrO2, Metal
Noise Reduction: B, C, S
Headroom Extension: HX Pro
Frequency Response: 20Hz to 20kHz (Metal tape)
Signal to Noise Ratio: 80dB (dolby S)
Wow and Flutter: 0.05%
Total Harmonic Distortion: 0.8%
Input: 100mV (line)
Output: 0.57V (line)
Dimensions: 435 x 126 x 277mm
Weight: 4.6kg
Year: (1994-97)

Yamaha NS-5 speakers
Specs.
Type: 2 way, loudspeaker system
Frequency Response: 55Hz to 30kHz
Power Handling: 80 Watts
Impedance: 6Ω
Sensitivity: 90dB
Bass: 1 x 130mm cone type
Tweeter: 1 x 25mm dome type
Enclosure: bass reflex
Dimensions: 206 x 338 x 250mm (WHD)
Weight: 6,5kg
Year: (1994)

Aandrukgewicht en LP's behoren niet tot de koop!

Kan uiteraard hier beluisterd worden.

Bekijk mijn andere advertenties, voor meer Vintage Audio !!!
